Ku-Band Satellite Transceiver Revision 9
FSK Remote Control Commands MN/KST2000AB.IOM
E-23
Parameter
Type
Command
(Instruction
Code and
qualifier)
Arguments for
Command or
Response to
Query
Description of arguments
(note that all arguments are ASCII numeric codes, that is, ASCII
codes between 48 and 57)
Response to Command (target to
controller)
Query
(Instruction
Code and
qualifier)
LNA Stored
Faults
n.a. 1 byte Query only.
<add/LSF?X’cr’
>add/LSF=A’cr’’lf’ or
>add/LSF=NO_FAULT’cr’’lf’
Where: A=LNA Status, 0=OK, 1=FLT
X= Stored Fault Locations (0 to 9)
LSF= (message ok)
LSF? (received ok, but invalid arguments
found)
LSF* (message ok, but not permitted in
current mode)
LSF?
AGC Stored
Faults
n.a. 3 bytes Query only.
<add/ASF?X’cr’
>add/ASF=ABC’cr’’lf’ or
>add/ASF=NO_FAULT’cr’’lf’
Where: A=Loop Convergence, 0=OK, 1=FLT
B=Excessive Input Power (EIP), 0=OK, 1=FLT
C=Insufficient Input Power (IIP), 0=OK, 1=FLT
X=Stored Fault Locations (0 to 9)
ASF= (message ok)
ASF? (received ok, but invalid arguments
found)
ASF* (message ok, but not permitted in
current mode)
ASF?
Common
Equipment
Stored Faults
n.a. 4 bytes Query only.
<add/CSF?X’cr’
>add/CSF=ABCD’cr’’lf’ or
>add/CSF=NO_FAULT’cr’’lf’
Where: A=–7V PS Status, 0=OK, 1=FLT
B=+7V PS Status, 0=OK, 1=FLT
C=+12V PS Status, 0=OK, 1=FLT
D=+17V PS Status, 0=OK, 1=FLT
X=Stored Fault Locations (0 to 9)
CSF= (message ok)
CSF? (received ok, but invalid arguments
found)
CSF* (message ok, but not permitted in
current mode)
CSF?
Clear Stored
Faults
CSA= None Command only.
<add/CSA=’cr’
>add/CSA=’cr’’lf’
CSA= (message ok)
CSA? (received ok, but invalid arguments
found)
CSA* (message ok, but not permitted in
current mode)
n.a.
- Ku-Band Satellite Transceive 1
- Installation and O 1
- KST-2000A/B 3
- Customer Service 4
- Table of Contents 5
- Figures 9
- Preface MN/KST2000AB.IOM 10
- Preface 11
- Related Documents 12
- Warranty Policy 13
- Chapter 1. INTRODUCTION 15
- 1.1 Description 16
- 1.1.3 Areas of Operation: 17
- 1.1.4 Features 18
- 1.1.4.2 Other Features 19
- Ku-Band & 20
- DC Power 20
- DC Power & 22
- 10 MHz Ref 22
- 1.1.7 Redundant System 23
- 1.2 Specifications 24
- to + 140°F) 26
- Notes: 27
- Chapter 2. INSTALLATION 29
- . (see Note) 30
- 2.3. Description of Options 31
- 2.4. Electrical Connections 32
- 2.4.1. Converter Unit 32
- 2.4.1.9 HPA Connector (J8) 38
- 2.4.2. Data SSPAs 41
- 2.4.3. LNA Connections 48
- 2.4.4. LNB Connections 48
- Chapter 3. OPERATION 49
- 3.1.1 Uplink Setup 51
- 3.1.2 Downlink Setup 52
- (2 places) 55
- PL/8085-2 55
- 3.4 Connector Descriptions 58
- 3.4.7 Other Connectors 63
- 3.5 Indicators Description 63
- Unit A Unit B 65
- 3.7 Reference Oscillator 70
- • Fault relays • ROM/RAM 72
- 3.11.1 Operation 77
- AND ISOLATION 81
- Chapter 4. FAULT INDICATION 81
- 4.2 Fault Isolation 82
- 4.3 Stored Faults 82
- Chapter 5. KEYPAD / DISPLAY 85
- 5.3 The Menu Structure 89
- 5.3.1 Configuration 90
- ] or [ X] to move the 91
- 5.3.2 Monitor 93
- 5.3.3 Faults 94
- 5.3.4 Utility 97
- 5.3.5 System 98
- or [ X] arrow buttons 99
- 5.3.6 Redundancy 100
- Operation MN/KST2000AB.IOM 102
- Appendix A. EQUIPMENT 103
- OUTLINE DRAWINGS 103
- TOLERANCE: +/- .02 (0.5) 108
- 5.67 (143.8) 110
- 5.12 (130.0) 110
- 2.55 (65) 110
- 1.58 (40) 110
- Type “N” 110
- Appendix B. TERMINAL MODE 111
- COMMANDS 111
- B.2 Message Structure 112
- B.2.1 Start Character 112
- B.2.2 Device Address 112
- B.2.3 Command/Response 113
- B.2.3 End Character 114
- B.3.3 Reset Commands 118
- <add/HS_’cr’ 119
- >add/HS_’cr’ 119
- B.3.5 Stored Faults 121
- B.3.6 Miscellaneous 124
- B.4.1 External Fault Mode 126
- Appendix C. SINGLE-THREAD 127
- EQUIPMENT MOUNTING 127
- C.1 Tools Required 128
- C.2.1 Spar Arm Mount 129
- Figure C-2 131
- C.2.2 Pole Mount 132
- Flat fitting plate 133
- Pipe block 133
- C.3 SSPA Installation 136
- C.4 LNA Installation 139
- C.5 Cable Installation 140
- Appendix D. REDUNDANT 141
- D.1 Tools Required 142
- D.2.1 Spar Arm Mount 143
- D.2.2 Pole Mount 146
- D.3 1:1 SSPA Installation 150
- D.4 1:1 LNA Installation 151
- D.5 Cable Installation 151
- Appendix E. FSK REMOTE 153
- CONTROL COMMANDS 153
- E.2 Basic Protocol 154
- E.2.1 Packet Structure 155
- E.2.2 Start Of Packet 155
- E.2.3 Address 155
- E.2.4 Instruction Code 155
- E.2.6 Message Arguments 158
- E.2.7 End Of Packet 158
- E.3 Commands and Query 158
- 2W SSPA – Item D=BV1 171
- Glossary 177
- Ω kilo-ohms 178
- Glossary MN/KST2000AB.IOM 180
