UT-4500A Series Upconverters Revision 0
Introduction MN-UT4500A
1–3
1.2.2 Dimensional Envelope
Dimensions are shown in both inches and centimeters.
1.75”
(4.45)
18.25
(46.35)
SAMPLE STATUS
RF IF
POWER ON
TRANSMIT
REMOTE
ON LINE
FAULT
STORED FAULT
ENT
CLR
17.00
(432)
19.0
(48.3)
22.00
(55.9)
Figure 1-3. UT-4500-A Series Upconverter Dimensional Envelope
