OM20 Universal Outdoor Modem Technical Specifications
MN-OM20– Revision 5 8–10
8.13.4 BER Performance (8PSK Trellis)
1E-9
1E-8
1E-7
1E-6
1E-5
1E-4
1E-3
1E-2
1E-1
0 1 2 3 4 5 6 7 8 9 10 11 12
Eb/No in dB
BER
Trellis
Decoder
Specification
2/3 Rate
Specification
2/3 Rate w/RS
Typical
Performance
8PSK Uncoded Theory
Note: Eb/No values include the effect of using Differential Decoding and V.35 Descrambling.
Figure 8-4. OM20 8PSK BER Performance (Trellis)
