Ku-Band Satellite Transceiver Revision 9
FSK Remote Control Commands MN/KST2000AB.IOM
E-7
Parameter
Type
Command
(Instruction
Code and
qualifier)
Arguments for
Command or
Response to
Query
Description of arguments
(note that all arguments are ASCII numeric codes, that is,
ASCII codes between 48 and 57)
Response to Command (target to
controller)
Query
(Instruction
Code and
qualifier)
Up Converter
Frequency
UFQ= 7 bytes Command or Query.
<add/UFQ=nnnnn.n’cr’
>add/UFQ=’cr’’lf’
<add/UFQ?’cr’
>add/UFQ=nnnnn.n’cr’’lf’
Where: nnnnn.n = 13750.0 to 14500.0 MHz, in 1 MHz steps
UFQ= (message ok)
UFQ? (received ok, but invalid arguments
found)
UFQ* (message ok, but not permitted in
current mode)
UFQ?
Down Converter
Frequency
DFQ= 7 bytes Command or Query.
<add/DFQ=nnnnn.n’cr’
>add/DFQ=’cr’’lf’
<add/DFQ?’cr’
>add/DFQ=nnnnn.n’cr’’lf’
Where: nnnnn.n = 10950.0 to 12750.0 MHz, in 1 MHz steps
DFQ= (message ok)
DFQ? (received ok, but invalid arguments
found)
DFQ* (message ok, but not permitted in
current mode)
DFQ?
Up Converter
Attenuation
UAT= 4 bytes Command or Query.
<add/UAT=nn.n’cr’
>add/UAT=’cr’’lf’
<add/UAT?’cr’
>add/UAT=nn.n’cr’’lf’
Where: nn.n = 00.0 to 20.0 dB, in 1.0 dB steps
UAT= (message ok)
UAT? (received ok, but invalid argument
found)
UAT* (message ok, but not permitted in
current mode)
UAT?
Down Converter
Attenuation
DAT= 4 bytes Command or Query.
<add/DAT=nn.n’cr’
>add/DAT=’cr’’lf’
<add/DAT?’cr’
>add/DAT=nn.n’cr’’lf’
Where: nn.n = 00.0 to 10.0 dB, in 1.0 dB steps
DAT= (message ok)
DAT? (received ok, but invalid arguments
found)
DAT* (message ok, but not permitted in
current mode)
DAT?
