Ku-Band Satellite Transceiver Revision 9
FSK Remote Control Commands MN/KST2000AB.IOM
E-14
Parameter
Type
Command
(Instruction
Code and
qualifier)
Arguments for
Command or
Response to
Query
Description of arguments
(note that all arguments are ASCII numeric codes, that is, ASCII
codes between 48 and 57)
Response to Command (target to
controller)
Query
(Instruction
Code and
qualifier)
System
Configuration
Status
n.a. 67 bytes Query only.
<add/RCS?’cr’
>add/RCS=’cr’
UFQ=nnnnn.n’cr’
DFQ=nnnnn.n’cr’
UMU=x’cr’
UAT=nn.n’cr’
DAT=nn.n’cr’
SEL=n’cr’
AGC=n’cr’
HPA=xy’cr’’lf’
Where: x=HPA power enable (as AMP)
y=HPA fault enable (as KFE)
Note: The converter configuration status command causes a block of
data to be returned by the addressed unit. The block of data reflects
the correct configuration status.
RCS= (message ok)
RCS? (received ok, but invalid arguments
found)
RCS* (message ok, but not permitted in
current mode)
RCS?
Retrieve Utility
Status
n.a. 17 bytes Query only.
<add/RUS?’cr’
>add/RUS=’cr’
BDR=9600’cr’
REF=nnn’cr’’lf’
Where: nnn = 000 to 255
RUS= (message ok)
RUS? (received ok,
but invalid argument found)
RUS* (message ok, but not permitted in
current mode)
RUS?
