OM20 Universal Outdoor Modem Web Browser/Remote Protocol
MN-OM20– Revision 5 6–48
Event Menu
Figure 6-23. Event Menu
Delete All: Cleans the entire event buffer.
Event Type:
I Informational
Y Yellow alarm. Indicates a transmit or receive warning condition.
R Red alarm. Indicates a transmit or receive failure,
losing traffic.
IM PO RTA NT
The Event Buffer may be sorted by warning level, time, date, or
event description. This feature may be used to further investigate
event occurrences.
