RCS20 M:N Redundancy Switch Revision 15

User Interfaces MN-RCS20 and CD-RCS20

4–44

4.3.2.16.1 Programming steps:

1. Use the numeric keypad to enter the desired backlight timeout value in seconds. Valid values are

0 to 255 seconds.

2. Press <CLR> or <NEXT> to abort programming (no switch parameters changed).

3. Press <ENT> to load the information on the screen into the switch parameter table. Switching will

occur immediately after pressing <ENT>.

Key Label Function

S1 --- N/A

S2 --- N/A

S3 --- N/A

S4 NEXT Press to cycle to the next screen.

Numeric Keypad ---

A value (in seconds) from 0 to 255 is entered.

Press <CLR> to disregard the value entered on the keypad, keep the previous value, and

cycle back to the LCD CONTRAST ADJUSTMENT Screen.

Press <ENT> to select the value entered on the keypad and cycle to the next screen.

4.3.2.17 BANK CONTROL CONFIGURATION

This screen displays disabling of IFS and DDS and combining IFL. To modify parameters, press S1, S2 or

S3.

Key Label Function

S1 IFS Press to cycle to the IFS BANK CONTROLLER Screen.

S2 DDS Press to cycle to the DDS BANK CONTROLLER Screen.

S3 IDL Press to cycle to the COMBINE IFL Screen.

S4 NEXT Press to cycle to the next screen.

Numeric Keypad --- N/A

BANK CONTROL CONFIGURATION

DISABLE IFS: NO

DISABLE DDS: NO

COMBINE IFL: NO

IFS DDS IDL NEXT
