CDM-840 Remote Router Revision 2
Ethernet-based Remote Product Management MN-CDM840
6–69
E1 Transmit Packet Statistics
From left to right:
Column
Description
E1 Priority
Priority as related to E1 configuration (inband signaling/configuration is always
conveyed as Priority 1).
QoS Index
System-assigned Quality of Service Index.
Tx Packets
Number of packets transmitted.
Dropped Packets
Number of packets dropped (errors or bandwidth limitations).
Tx Packet Rate (pkts/s)
Packet rate (packets per second).
Tx Data Rate (kbps)
Data rate ( kilo bits per second).
Click [Refresh] to update this section with its latest available statistics.
Click [Clear] to clear all E1 Transmit Packet statistics from the buffer.
E1 Transmit Statistics
Row
Description
Compression Error Count
Number of compression errors detected.
Tx Status Packet Count
Number of status packets transmitted (status packets are transmitted every
500ms).
Click [Refresh] to update this section with its latest available statistics.
Click [Clear] to clear all E1 Transmit Packet statistics from the buffer.
Transmit Time Slot Status (Auto Detected)
• Slot – Numbered 0 through 31.
• Type – Slots are detected as Idle or Active. Idle time slots, once detected, do not utilize
bandwidth.
Click [Refresh] to update this section with its latest available statistics.
- MN-CDM840 Revision 2 1
