CDM-840 Remote Router Revision 2
Ethernet-based Remote Product Management MN-CDM840
6–71
E1 Receive Statistics
From left to right:
Row
Description
Decompression Error Count
Number of decompression errors detected..
Receive Status Packet Count
Number of status packets received (status packets are received every
500ms).
Jitter Buffer Overflow Count
Number of times that the jitter buffer has overflowed (indicates too
much data; jitter latency is not set high enough if count increases
consistently).
Jitter Buffer Underflow Count
Number of times that the jitter buffer has underflowed (indicates not
enough data; jitter latency is not set high enough if count increases
consistently.
Click [Refresh] to update this section with its latest available statistics.
