CDM-840 Remote Router Revision 2
Serial-based Remote Product Management MN-CDM840
7–22
Parameter
Type
Command
(Instruction
Code
& Qualifier)
Number of
Arguments for
Command or
Response to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code &
Qualifier)
Response to Query
(Target to Controller)
Faults and
Status
N/A
16 bytes
Query only.
Returns the current highest-priority fault and status codes for the Unit (hardware),
TX Traffic, RX Traffic, and ODUs in the form abcdefxxxxxxxxxx, where:
a = Unit status:
0=No faults
1=Power supply fault, +5 volts
2=Power supply fault , +12 volts
3=Tx synthesizer unlocked
4=Tx/Rx FPGA PLL unlocked
5=Tx/Rx FPGA load fail
6=Compression FPGA load fail
b = Tx Traffic status:
0=Tx traffic OK
c = Rx Traffic status:
0=Rx Traffic OK
1=Demodulator unlocked
2=Es/No Alarm
d = BUC status/faults:
0=BUC OK
1=BUC Current
2=BUC Voltage
e = LNB status/faults:
0 = OK, masked or not present
1 = LNB current
2 = LNB voltage
f = Traffic/GE Interface Fault (reports as Unit Fault)
0 = OK
1 = No Link
sssssssssssssssssss (10 spares)
Example: <0/FLT?’cr’
N/A
FLT?
FLT= abcdefxxxxxxxxxx
(see Description of
Arguments)
Software
Boot From
Slot
SBS=
1 byte
Command or Query.
Selects which bulk firmware slot to boot from in the form x, where:
0=Latest Firmware (most recent date)
1=Firmware is Slot #1
2=Firmware is Slot #2
Example: <1/SBS=1’cr’
SBS=
SBS?
SBS*
SBS#
SBS?
SBS=x
(see Description of
Arguments)
