CDM-840 Remote Router Revision 2
Serial-based Remote Product Management MN-CDM840
7–20
Parameter
Type
Command
(Instruction
Code
& Qualifier)
Number of
Arguments for
Command or
Response to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code &
Qualifier)
Response to Query
(Target to Controller)
Equipment ID
(cont.)
D=E1 Interface – WAN Adaptation:
0= None
1= 1 TRX (up to 3 DSO can be selected)
2= 2 TRX (up to 6 DSO can be selected)
3= 3 TRX (up to 9 DSO can be selected)
4= 6 TRX (up to 18 DSO can be selected)
5= 9 TRX (up to 27 DSO can be selected)
6= 9+ TRX / Full E1 (up to 32 DSO can be selected)
E=Header Compression Tx Data Rate (CCM)/ Symbol Rate (ACM):
0= None
1= up to 256 kbps (CCM) / 100 ksps (ACM)
2= up to 512 kbps (CCM) / 200 ksps (ACM)
3= up to 1024 kbps (CCM) / 400 ksps (ACM)
4= up to 2048 kbps (CCM) / 800 ksps (ACM)
5= up to 5 Mbps (CCM) / 1200 ksps (ACM)
6= up to 10 Mbps (CCM) / 2400 ksps (ACM)
7= up to 15 Mbps (CCM) / 4100 ksps (ACM)
F=Header Decompression Rx Data Rate (CCM)/ Symbol Rate (ACM):
0= None
1= up to 15 Mbps (CCM) / 5 Msps (ACM)
2= up to 45 Mbps (CCM) / 15 Msps (ACM)
3= up to 100 Mbps (CCM) / 34 Msps (ACM)
4= up to 140 Mbps (CCM) / 47 Msps (ACM)
5= up to 167 Mbps (CCM) / 62 Msps (ACM)
G=Payload Compression Tx Data Rate (CCM)/ Symbol Rate (ACM):
0= None
1= up to 256 kbps (CCM) / 100 ksps (ACM)
2= up to 512 kbps (CCM) / 200 ksps (ACM)
3= up to 1024 kbps (CCM) / 400 ksps (ACM)
4= up to 2048 kbps (CCM) / 800 ksps (ACM)
5= up to 5 Mbps (CCM) / 1200 ksps (ACM)
6= up to 10 Mbps (CCM) / 2400 ksps (ACM)
7= up to 15 Mbps (CCM) / 4100 ksps (ACM)
H=Payload Decompression Rx Data Rate (CCM)/ Symbol Rate (ACM):
0= None
1= up to 15 Mbps (CCM) / 5 Msps (ACM)
2= up to 45 Mbps (CCM) / 15 Msps (ACM)
3= up to 100 Mbps (CCM) / 34 Msps (ACM)
4= up to 140 Mbps (CCM) / 47 Msps (ACM)
5= up to 167 Mbps (CCM) / 62 Msps (ACM)
