CDM-840 Remote Router Revision 2
Serial-based Remote Product Management MN-CDM840
7–16
7.3.5 Transmit (Tx) BERT Command or Query
Parameter
Type
Command
(Instruction
Code
& Qualifier)
Number of
Arguments for
Command or
Response to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code &
Qualifier)
Response to Query
(Target to Controller)
Tx BERT
State
BTX=
1 byte
Command or Query.
Sets or returns Tx BERT State in the form x, where:
0=Off
1=On
Example: <1/BTX=1’cr’
BTX=
BTX?
BTX#
BTX?
BTX=x
(see Description of
Arguments)
7.3.6 Receive (Rx) BERT Command or Query
Parameter
Type
Command
(Instruction
Code
& Qualifier)
Number of
Arguments for
Command or
Response to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code &
Qualifier)
Response to Query
(Target to Controller)
Rx BERT
State
BRX=
1 byte
Command and Query
Sets or returns Rx BERT state in the form x, where:
0 = off
1 = on
Example: <1/BRX=1’cr’
BRX =
BRX?
BRX *
BRX #
BRX?
BRX=x
(see description of
arguments)
