CDM-840 Remote Router Revision 2
Serial-based Remote Product Management MN-CDM840
7–17
7.3.7 BUC (Block Upconverter) Parameters Commands and Queries
Parameter
Type
Command
(Instruction
Code
& Qualifier)
Number of
Arguments for
Command or
Response to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code &
Qualifier)
Response to Query
(Target to Controller)
BUC Power
Supply
enable
BPS=
1 byte
Command or Query.
Sets or returns the BUC Power Supply control in the form x, where:
0=Disable
1=Enable
Example: <1/BPS=1’cr’
BPS=
BPS?
BPS*
BPS#
BPS?
BPS=x
(see Description of
Arguments)
BUC 10
MHz
Reference
BFR=
1 byte
Command or Query.
Sets or returns the BUC 10 MHz Reference control in the form x, where:
0=Off
1=On
Example: <1/BFR=1’cr’
BFR=
BFR?
BFR*
BFR#
BFR?
BFR=x
(see Description of
Arguments)
BUC
Current Low
Limit
BCL=
4 bytes
Command or Query.
Sets or returns the BUC Current Low Limit in the form xxxx, where:
xxxx = a value from 0 to 4000mA, in 100mA increments.
Example: <1/BCL=1200’cr’
BCL=
BCL?
BCL*
BCL#
BCL?
BCL=xxxx
(see Description of
Arguments)
BUC
Current
High Limit
BCH=
4 bytes
Command or Query.
Sets or returns the BUC Current High Limit in the form xxxx, where:
xxxx = a value from 0 to 4000mA, in 100mA increments
Example: <1/BCH=2300’cr’
BCH=
BCH?
BCH*
BCH#
BCH?
BCH=xxxx
(see Description of
Arguments)
BUC DC
Current
N/A
4 bytes
Query only.
Returns the value of the BUC DC current in the form xxxx, where:
xxxx = a value, in mA, from 0 to 9999.
If not available, response is 0000.
Example: <1/BDC?’cr’
N/A
BDC?
BDC=xxxx
(see Description of
Arguments)
BUC
Voltage
N/A
4 bytes
Query only.
Returns the value of the BUC Voltage in the form xx.x, where:
xx.x = a value, in volts, from 0 to 64.0
Example: <1/BDV?’cr’
N/A
BDV?
BDV=xx.x
(see Description of
Arguments)
